Latest Type PMMA Plastic Frame Caravan and Motorhome Side Window
Anhui Maygood RV Accessories Co., Ltd.- After-sales Service：Factory After-Sale Service
- Warranty：12 Months
- Type：Side Window
- Function：Anti-Insect
- Glass Composition：Acrylic
- Certification：ECE
Base Info
- Model NO.：MG16RW
- Glass：Acrylic
- Transport Package：Pakced in Plywood Case or Carton Pallet
- Specification：E4
- Trademark：MAYGOOD
- Origin：China
- HS Code：87169000
- Production Capacity：4000 PCS Per Month
Description
Overview
Product DescriptionProduct Parameters
| No. | Ordering Size W*H | Weight (kg) | Overall size | Cut-out size | Corner Radius ( R ) | Clear Opening of the hinged window |
| 1 | 350 × 280 | 2.5 | 380×310 | 350×280 | 7mm | 228×158 |
| 2 | 500 × 350 | 4.10 | 530×380 | 500×350 | 7mm | 378×228 |
| 3 | 350 × 500 | 4.10 | 380×530 | 350×500 | 7mm | 228×378 |
| 4 | 500 × 450 | 4.70 | 530×480 | 500×450 | 7mm | 378×328 |
| 5 | 450 × 500 | 4.70 | 480×530 | 450×500 | 7mm | 328×378 |
| 6 | 500 × 500 | 5.10 | 530×530 | 500×500 | 7mm | 378×378 |
| 7 | 500 × 550 | 5.30 | 530×580 | 500×550 | 7mm | 378×428 |
| 8 | 500 × 600 | 6.0 | 530×630 | 500×600 | 7mm | 378×478 |
| 9 | 600 × 600 | 6.1 | 630×630 | 600×600 | 7mm | 478×478 |
| 10 | 700 × 400 | 5.8 | 730×430 | 700×400 | 7mm | 578×278 |
| 11 | 800 × 500 | 7.5 | 830×530 | 800×500 | 7mm | 678×378 |
| 12 | 800 × 900 | 10.5 | 830×930 | 800×900 | 7mm | 678×778 |
| 13 | 900 × 450 | 7.10 | 930×480 | 900×450 | 7mm | 778×328 |
| 14 | 900 × 500 | 7.80 | 930×530 | 900×500 | 7mm | 778×378 |
| 15 | 900 × 550 | 8.10 | 930×580 | 900×550 | 7mm | 778×428 |
| 16 | 900 × 900 | 13.2 | 930×930 | 900×900 | 7mm | 778×778 |
| 17 | 1000 × 500 | 8.4 | 1030×530 | 1000×500 | 7mm | 878×378 |
| 18 | 1000 × 600 | 9.2 | 1030×630 | 1000×600 | 7mm | 878×478 |
| 19 | 1000 × 800 | 11.30 | 1030×830 | 1000×800 | 7mm | 878×678 |
| 20 | 1100 × 450 | 8.60 | 1130×480 | 1100×450 | 7mm | 978×328 |
| 21 | 1100 × 550 | 9.60 | 1130×580 | 1100×550 | 7mm | 978×428 |
| 22 | 1200 × 350 | 7.00 | 1230×380 | 1200×350 | 7mm | 1078×228 |
| 23 | 1200 × 500 | 10.00 | 1230×530 | 1200×500 | 7mm | 1078×378 |
| 24 | 1200 × 700 | 11.5 | 1230×730 | 1200×700 | 7mm | 1078×378 |
| 25 | 1200 × 800 | 13.00 | 1230×830 | 1200×800 | 7mm | 1078×678 |
| 26 | 1450 × 550 | 11.70 | 1480×580 | 1450×550 | 7mm | 1328×428 |
| 27 | 1530 × 380 | 9.6 | 1560×410 | 1530×380 | 7mm | 1408×258 |
