• Model NO.：BMWR
• Loading：350kg
• Net Weight：45kg
• Operation Method：Manual
• Gorss Weight：70kg
• Platform：Anti-Skip
• Overall Height：1050mm
• Overall Width：880mm
• Transport Package：Wooden Case
• Specification：810*1910mm
• Trademark：xinder
• Origin：Jiangsu
• HS Code：8708999990
• Production Capacity：1000PCS

Basic Info.

Model NO. BMWR Loading 350kg Net Weight 45kg Operation Method Manual Gorss Weight 70kg Platform Anti-Skip Overall Height 1050mm Overall Width 880mm Transport Package Wooden Case Specification 810*1910mm Trademark xinder Origin Jiangsu HS Code 8708999990 Production Capacity 1000PCS

Product Description

Introductions:

• This wheelchair ramp is a kind of manual ramp which can be used for rear door of commercial vehicle.

• It can help a person to get on vehicle easily and comfortably while seated in a wheelchair.

• This ramp consists of three honeycombs plates which are hinged joint to fold and unfold.

• Main material is aluminum which is light and with high corrosion resistance.

• Platform equips with black-yellow anti-skip covering, which is more beautiful.



 Advantages.

• two gas springs at the two sides of ramp, which make the operation easy;

• anti-skip platform;



Technical Specifications:

• Loading capacity: 350kg;

Because of the compact design, this ramp can be used for mini-vehicle such as wagon, light-van, van, and minivan and so on.

Model	Platform Net Size  (A×B)	Overall width (C)	Overall height (D)	Overall Length (E)	Loading capacity	Own weight
BMWR-201	1910×810	880 mm	1050 mm	265 mm	350 Kg	40 Kg
BMWR-202	2310×810	880 mm	1250 mm	265 mm	350 Kg	40 Kg
